2-8
Cisco 7200 Series Port Adapter Hardware Configuration Guidelines
OL-3875-11
Chapter 2 Memory Requirements
SDRAM and DRAM Options for NPEs and the NSE
Table 2-11 DRAM Options for the NPE-100, NPE-150, and NPE-200
DRAM Option
NPE-100 NPE-150 NPE-200
Processor
Memory I/O Memory
Processor
Memory I/O Memory
1
1. The I/O memory for the NPE-150 DRAM options includes 1 MB of packet SRAM.
Processor
Memory I/O Memory
2
2. The I/O memory for the NPE-200 DRAM options includes 4 MB of packet SRAM.
32 MB 26 MB 6 MB 26 MB 7 MB 26 MB 10 MB
64 MB 56 MB 8 MB 56 MB 9 MB 56 MB 12 MB
128 MB 120 MB 8 MB 120 MB 9 MB 120 MB 12 MB
3
3. For Cisco 7206 router shelf memory requirements, refer to the Cisco AS5800 Universal Access Server documentation at
http://www.cisco.com/univercd/cc/td/doc/product/access/acs_serv/as5800/index.htm.
