Chapter 2 Overview: Cisco 7600 Series SIPs
Identifying Slots and Subslots for SIPs and SPAs
Some commands allow you to display information about the SIP itself, such as show module, show
sip-disk, show idprom module, show hw-module slot, and show diagbus. These commands require
you to specify the chassis slot location where the SIP that you want information about is installed.
For example, to display status and information about the SIP installed in slot 6 as shown in Figure 2-1,
enter the following command:
Router# show module 6
For more information about SIP commands, refer to the Cisco IOS Software Releases 12.2SR Command
References and to the Cisco IOS Software Releases 12.2SX Command References.
Specifying the SIP or SSC Subslot Location for a SPA
SIP subslots begin their numbering with “0” and have a horizontal or vertical orientation depending on
the orientation of the SIP in the router chassis slot, as shown in the “SIP, SSC, and SPA Product
Overview” chapter of the Cisco 7600 Series Router SIP, SSC, and SPA Software Configuration Guide.
1 SIP subslot 0 4 SIP subslot 3
2 SIP subslot 1 5 Chassis slots 1–9 (numbered from right to left)
(numbered from top to bottom)
3 SIP subslot 2
