5-42
Cisco 7600 Series Router Installation Guide
OL-4503-24
Chapter 5 Removal and Replacement Procedures
Removing and Replacing the Power Supply
• Installing a PWR-2700-DC/4 Power Supply in a Cisco 7604 Router, page 5-45
• Installing a PWR-1900-DC Power Supply in a Cisco 7606 Router, page 5-50
• Installing a PWR-2700-DC Power Supply in a Cisco 7606 Router, page 5-52
• Installing a PWR-2700-DC Power Supply in a Cisco 7606-S Router, page 5-56
• Installing a WS-CDC-2500W Power Supply in a Cisco 7609 Router, page 5-60
• Installing a WS-CDC-2500W Power Supply in a Cisco 7613 Router, page 5-63
• Installing a PWR-4000-DC Power Supply in a Cisco 7609 Router or a Cisco 7609-S Router, page
5-65
• Installing a PWR-6000-DC Power Supply in a Cisco 7609 or a Cisco 7609-S Router, page 5-74
• Installing a PWR-4000-DC Power Supply in a Cisco 7613 Router, page 5-86
• Installing a PWR-6000-DC Power Supply in a Cisco 7613 Router, page 5-94
Note The DC return is to remain isolated from the system frame and chassis (DC-I).
Installing a PWR-950-DC Power Supply in a Cisco 7603 Router
Warning
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Follow these steps to install a DC-input power supply:
Step 1 Ensure that the system (earth) ground connection has been made. For ground connection installation
instructions, see the “System Ground Connection” section on page 3-19.
Step 2 Verify that power is off to the DC circuit connected to the DC PEM for the power supply you are
installing.
Step 3 Grasp the power supply handle with one hand. Place your other hand underneath the power supply, as
shown in Figure 5-46. Slide the power supply into the power supply bay. Make sure that the power
supply is fully seated in the bay.
