19
Catalyst 6509 Switch, Cisco 7606 Router, and Cisco 7609 Router with VPN Services Module Certification Note
OL-6334-01
Physical Security
• Place one label so that one half of the label adheres to the right side of the opacity shield and
the other half adheres to the chassis.
• For the Catalyst 6509 switch chassis only, place one label so that one half of the label adheres
to the bottom of the opacity shield and the other half adheres to the right side of the chassis.
• For the Cisco 7606 router chassis only, place one label so that one half of the label adheres to
the bottom of the opacity shield and the other half adheres to the bottom of the chassis.
Note The Cisco 7609 router does not have an opacity shield.
Step 3 Place labels on each supervisor engine installed in the chassis as shown in either Figure 7 (Catalyst 6509
switch), Figure 8 (Cisco 7606 router), or Figure 9 (Cisco 7609 router).
a. Place a tamper evidence label so that one half of the label adheres to the PCMCIA slot and the other
half adheres to the Supervisor Engine 2 faceplate. Any attempt to install or remove a Flash PC card
will damage the tamper seal, which indicates tampering has occurred.
b. Place a tamper evidence label so that one half of the label adheres to the GBIC transceiver installed
in the supervisor engine 2 network interface uplink port and the other half adheres to the Supervisor
Engine 2 faceplate. Any attempt to remove a GBIC transceiver will damage the tamper seal, which
indicates tampering has occurred.
c. Place a tamper evidence label so that it completely covers an unpopulated network interface uplink
port. Any attempt to install a GBIC transceiver in the network interface uplink port will damage the
tamper seal, which indicates tampering has occurred.
Note The tamper seal label adhesive completely cures within five minutes.
Figure 7 Catalyst 6509 Switch Chassis Tamper Evidence Label Placement
FAN
S
TA
TU
S
INPUT
OK
FAN
OK
OUTPUT
FAIL
o
INPUT
OK
FAN
OK
OUTPUT
FAIL
o
1
2
3
4
5
6
7
8
9
IPSec VPN Acceleration Services Module
WS-SVC-IPSEC-1
S
T
A
T
U
S
S
U
P
E
R
V
IS
O
R
2
W
S
-X
6
K
-S
U
P
2
-2
G
E
S
T
A
T
U
S
S
Y
S
T
E
M
C
O
N
S
O
L
E
P
W
R
M
G
M
T
R
E
S
E
T
C
O
N
S
O
L
E
C
O
N
S
O
L
E
P
O
R
T
M
O
D
E
P
C
M
C
I
A
E
J
E
C
T
P
O
R
T
1
P
O
R
T
2
S
w
i
t
c
h
L
o
a
d
1
0
0
%
1
%
LINK
LIN
K
130878
