Catalyst 6509 Switch, Cisco 7606 Router, and Cisco 7609 Router with VPN Services Module Certification Note
OL-6334-01
Catalyst 6509/Cisco 7606/Cisco 7609 Cryptographic Module
Table 1 Catalyst 6509 Switch and Cisco 7606 and 7609 Router LEDs
LED Color/State Description
STATUS Green All diagnostics pass. The module is operational (normal
initialization sequence).
Orange The module is booting or running diagnostics (normal initialization
sequence).
An over-temperature condition has occurred. (A minor temperature
threshold has been exceeded during environmental monitoring.)
Red The diagnostic test failed. The module is not operational because a
fault occurred during the initialization sequence.
An over-temperature condition has occurred. (A major temperature
threshold has been exceeded during environmental monitoring.)
SYSTEM
1
Green All chassis environmental monitors are reporting OK.
Orange The power supply has failed or the power supply fan has failed.
Incompatible power supplies are installed.
The redundant clock has failed.
One VTT
2
module has failed or the VTT module temperature minor
threshold has been exceeded.
Red Two VTT modules fail or the VTT module temperature major
threshold has been exceeded.
The temperature of the supervisor engine major threshold has been
exceeded.
3
ACTIVE Green The supervisor engine is operational and active.
Orange The supervisor engine is in standby mode.
POWER MGMT Green Sufficient power is available for all modules.
Orange Sufficient power is not available for all modules.
SWITCH LOAD If the switch is operational, the switch load meter indicates (as an
approximate percentage) the current traffic load over the backplane.
PCMCIA The PCMCIA LED is lit when no Flash PC card is installed in the
slot, and it goes off when you insert a Flash PC card.
LINK Green The port is operational.
Orange The link has been disabled by software.
Flashing
Orange
The link is bad and has been disabled due to a hardware failure.
Off No signal is detected.
