1-12
Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 810 Series
Figure 1-6 Cisco 819HGW Integrated Services Router
Figure 1-7 shows the front panel details of the Cisco 819HG ISR.
Figure 1-7 Cisco 819HG ISR Front Panel
285479
245547
1 43 6 7 9 10 11 12
5 8
2
1 3G main antenna 7 FE ports
2 LEDs 8 GE WAN port
3 Reset button 9 Console/Aux port
