Chapter 3 Connecting the Router
Cisco 860, 880, 890 Series
Step 2 To secure the power cord to the router, attach the power lock clip to the power cord, slide the clip to the
end of the DC plug, and secure the retaining clip into the router chassis. See Figure 3-34.
Figure 3-34 Securing the Power Cord
1 Power lock clip 3 DC plug
2 Power cord 4 Lock holes on either side of the power
connector
270659
4
2
1
3
