Cisco Aironet Dual-Band MIMO Wall-Mounted Omnidirectional Antenna (AIR-ANT2544V4M-R)
78-20770-01
Technical Specifications
The figures below show the azimuth plane patterns (indicated by red lines) and elevation plane patterns
(indicated by blue lines) for each element in the antenna.
2.4-GHz Antenna 1 Azimuth and Elevation Plane Patterns 5-GHz Antenna 1 Azimuth and Elevation Plane Patterns
2.4-GHz Antenna 2 Azimuth and Elevation Plane Patterns 5-GHz Antenna 2 Azimuth and Elevation Plane Patterns
