Basic Configuration Using the Command-Line Interface
Configuring ISDN PRI
14
Cisco AS5350XM and Cisco AS5400XM Universal Gateways Software Configuration Guide
Under the channelized T3 controller, the T1 controller numbering convention is slot/port:channel in CLI
commands. Port numbering values range from 1 to 28.
Configure
Command Purpose
Step 1
AS5400> enable
Password: password
AS5400#
Enters enable mode. Enters the password. You are
in enable mode when the prompt changes to
AS5350# or AS5400#.
Step 2
AS5400# configure terminal
Enter configuration commands, one per line.
End with CNTL/Z.
AS5400(config)#
Enters global configuration mode. You are in
global configuration mode when the prompt
changes to
AS5350(config)# or
AS5400(config)#.
Step 3
AS5400(config)# isdn switch-type
switch-type
Selects a service provider switch type that
accommodates PRI. (See Table 5 for a list of
supported switch type keywords.)
Step 4
AS5400(config)# controller t1 1/0
or
AS5400(config)# controller e1 1/0
Specifies T1 feature card slot, port number, and
channel. On the CT3 feature card, port-number
values range from 1 to 28. On the T1 feature card,
port-number values range from 0 to 7.
or
Specifies E1 feature card slot, port number, and
channel. On the E1 feature card, port number
values range from 0 to 7.
Note After you configure the T1or E1
controller, a corresponding D-channel
serial interface is created instantly. See the
“Configuring the D Channels for ISDN
Signaling” section on page 22 to learn how
to configure your D channel.
Step 5
AS5400(config-controller)# framing esf
or
AS5400(config-controller)# framing crc4
Enters framing type for the T1 or CT3 feature
card.
or
Enters framing type for the E1 feature card.
Step 6
AS5400(config-controller)# linecode b8zs
or
AS5400(config-controller)# linecode hdb3
Defines the line code as binary 8 zero substitution
(B8ZS) for the T1 or CT3 feature card.
or
Defines the line code as high-density bipolar 3
(HDB3) for the E1 feature card.
