Basic Configuration Using the Command-Line Interface
Configuring ISDN PRI
15
Cisco AS5350XM and Cisco AS5400XM Universal Gateways Software Configuration Guide
For channelized T1 ISDN PRI—If you do not specify the timeslots, the specified controller is configured
for 23 B channels and 1 D channel. B channel numbers range 1 to 23; channel 24 is the D channel for
T1. Corresponding serial interface numbers range 0 to 23. In commands, the D channel is interface
serial slot/port:23—for example, interface serial 1/0:23.
For channelized E1 ISDN PRI—If you do not specify the timeslots, the specified controller is configured
for 30 B channels and 1 D channel. B channel numbers range 1 to 31; channel 16 is the D channel for
E1. Corresponding serial interface numbers range 0 to 30. In commands, the D channel is interface
serial slot/port:15—for example, interface serial 1/0:15.
Verify
To verify that you have configured the interfaces correctly, use the following commands:
• Enter the show controller t3 command and specify the slot and port numbers. Verify that the
controller is up and that you do not have excessive errors; otherwise your controller might go down
frequently. This could indicate switch problems.
AS5400# show controller t3 1/0
T3 1/0 is up.
Applique type is Channelized T3
No alarms detected.
MDL transmission is disabled
Step 7
AS5400(config-controller)# pri-group
[timeslots range]
1
Configures ISDN PRI.
If you do not specify the timeslots, the controller
is configured for 23 B channels and 1 D channel.
Step 8
AS5400(config-controller)# Ctrl-Z
AS5400#
Returns to enable mode.
1. For T1, timeslots range 1 to 24. You can specify a range of timeslots (for example, pri-group timeslots 12-24) if other
timeslots are used for non-PRI channel groups.
Command Purpose
Table 5 ISDN Service Provider PRI Switch Types
Area Keyword Switch Type
none none No switch defined
Australia primary-ts014 Australia PRI switches
Europe primary-net5 European, New Zealand, and Asia ISDN PRI
switches (covers the Euro-ISDN E-DSS1
signaling system and is European
Telecommunication Standards Institute or
ETSI-compliant)
Japan primary-ntt Japanese ISDN PRI switches
North America primary-4ess AT&T 4ESS switch type for the United States
primary-5ess AT&T 5ESS switch type for the United States
primary-dms100 NT DMS-100 switch type for the United States
primary-ni National ISDN switch type
