Cisco ASA 55 Series Hardware Installation Guide

About the ASA 5500-X
ASA Chassis Panels
Cisco ASA 5512-X, ASA 5515-X, ASA 5525-X, ASA 5545-X, and ASA 5555-X Hardware Installation Guide
15
Rear Panel LEDs
Figure 3 shows the rear panel LEDs for the ASA 5500-X.
4 Hard-disk release button Releases hard-disk 0 from the device.
5 Hard-disk slot Indicates the slot for hard-disk 0.
6 Alarm System operating status:
 Off—Normal operating system function.
 Solid amber—Critical Alarm indicating one or more of the following:
— a major failure of a hardware or software component.
— an over-temperature condition.
— power voltage is outside of the tolerance range.
Note: May appear red on some devices.
7 VPN VPN tunnel status:
 Solid green—VPN tunnel is established.
 Off—No VPN tunnel established.
8 HD1 Hard Disk Drive 1 status:
 Flashing green—Proportioned to read/write activity.
 Solid amber—Hard-disk drive failure.
 Off—No hard-disk drive present.
9 HD0 Hard Disk Drive 0 status:
 Flashing green—Proportioned to read/write activity.
 Solid amber—Hard-disk drive failure.
 Off—No hard-disk drive present.
1
0
PS1 Status of the optional redundant power supply.
1
1
PS0 Status of the primary power supply that ships with the product.
1
2
Active Status of the failover pair:
 Solid green—Failover pair is operating normally.
 Off—Failover pair is not operational.
1
3
Boot Power-up diagnostics:
 Flashing green—Power-up diagnostics are running, or system is booting.
 Solid green—System has passed power-up diagnostics.
 Off—Power-up diagnostics are not operational.
