Cisco ASA 55 Series Hardware Installation Guide

Identifying Cable Pinouts
Gigabit and Fibre Channel Ports
Cisco ASA 5512-X, ASA 5515-X, ASA 5525-X, ASA 5545-X, and ASA 5555-X Hardware Installation Guide
74
Gigabit and Fibre Channel Ports
Table 4 lists the types of SFP modules and connectors used in the ASA.
Table 5 lists the SFP port cabling specifications for the SFP modules and connectors used in the ASA.
TP1- 5
TP3+ 7
TP3- 8
Table 3 10/100/1000BASE-T Management Port Cable Pinouts (MDI)
Signal Pin
Table 4 Types of SFP Modules and Connectors
Port Compliance Connector Fiber Type
Gigabit Ethernet 1000BASE-SX SW MMF
1000BASE-LX LW SMF
Table 5 SFP Port Cabling Specifications
Cisco Product
Number
Wavelength
(nanometer)
Core Size
(micron)
Baud
Rate
Cable
Distance
GLC-SX-MM= 850 62.5
50.0
1.0625
1.0625
300 m
500 m
GLC-LH-SM= 1300 9.0 1.0625 10 km
