Figure 17: Placing the Switch on the DIN-Mount Tray
DIN rail mount2Switch1
Step 2 Use the two number-10 Phillips pan-head screws to secure the DIN rail mount to the switch.
Cisco Catalyst 1000 Series 8-Port and 16-Port Switch Hardware Installation Guide
26
Switch Installation
Attaching the DIN-Mount Tray to the Switch
