Example:
<pool name> is the name of the DHCP pool, such as AP9124AX
<IP Network> is the network IP address where the controller resides, such as 10.0.15.1
<Netmask> is the subnet mask, such as 255.255.255.0
<Default router> is the IP address of the default router, such as 10.0.0.1
<DNS Server> is the IP address of the DNS server, such as 10.0.10.2
Step 3 Add the option 43 line using the following syntax:
Example:
option 43 hex <hex string>
The hex string is assembled by concatenating the TLV values shown below:
Type + Length + Value
For example, suppose that there are two controllers with management interface IP addresses, 10.126.126.2
and 10.127.127.2. The type is f1(hex). The length is 2 * 4 = 8 = 08 (hex). The IP addresses translate to 0a7e7e02
and 0a7f7f02. Assembling the string then yields f1080a7e7e020a7f7f02. The resulting Cisco IOS command
added to the DHCP scope is option 43 hex f1080a7e7e020a7f7f02.
Cisco Catalyst 9124AX Series Outdoor Access Point Hardware Installation Guide
87
Troubleshooting
Configuring DHCP Option 43
