Cisco Catalyst 4500 Series Quick Reference Guide

30
Cisco Catalyst 6500 Series
Chassis
WS-C6503-E WS-C6504-E WS-C6506-E WS-C6509-E WS-C6509-NEB-A WS-C6513
Slots 3 4 6 9 9 13
Gigabit Ethernet GBIC/SFP density
98 144 242 386 384 410
10 GbE XENPAK/X2 port density
8 12 20 32 32 20
10/100/1000 density
97 144 241 385 385 577
10/100 density
192 288 480 768 768 1152
100BASE-FX density
96 144 240 384 384 576
Max. watt power consumption
(redundant mode)
AC Internal (redundant mode) 1,400
2,700 6,000 6,000 6,000 6,000
AC External with power shelf (redundant mode) N/A N/A N/A N/A N/A N/A
DC Internal (redundant mode) 950 2,700 4,000 4,000 4,000 4,000
Max. number of Class 3 devices (15.4W)
Max. power supplies
AC Internal (redundant mode)
48 110 284 288 215 281
AC External with power shelf (redundant mode) N/A N/A N/A N/A N/A N/A
DC Internal (redundant mode) 31 110 173 184 206 176
Dimension (H x W x D) inches 7 x 17.37 x 21.75 8.75 x 17.5 x 21.75 19.2 x 17.5 x 18.2 24.5 x 17.5 x 18.2 33.3 x 17.2 x 18.1 33.3 x 17.3 x 18.1
Dimension (H x W x D) centimeters 17.8 x 44.1 x 55.2 22.2 x 44.5 x 55.2 48.8 x 44.5 x 46.0 62.2 x 44.5 x 46.0 84.6 x 43.7 x 46.0 84.6 x 43.7 x 46.0
Rack Unit (RU) 4 5 12 15 21 20
Unit weight pounds (kilograms) (chassis only) 33 (15.0) 40 (18.1)
50 (22.7) 60 (27.3) 55 (24.9) 98 (45.0)
Hardware Features: Catalyst 6500 Chassis

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
