Cisco Catalyst 4500 Series Quick Reference Guide

34
35
Cisco Catalyst 6500 Series
CATA LY S T 6 5 0 0 — 10 / 10 0 / 1 0 0 0 E T H E R N E T
Product Number Description
WS-X6148A-GE-TX
48-port 10/100/1000 with Jumbo Frame, RJ-45
WS-X6148A-GE-45AF
48-port PoE 802.3af 10/100/1000, with Jumbo Frame
WS-X6516-GE-TX
16-port 10/100/1000 Gigabit Ethernet module, cross-bar
WS-X6548-GE-TX
48-port fabric-enabled 10/100/1000 module
WS-X6548-GE-45AF
PoE 802.3af 10/100/1000 48-port (RJ-45) CEF256 card
WS-X6748-GE-TX
48-port 10/100/1000 Gigabit Ethernet module, fabric-enabled, RJ-45
CATA LY S T 6 5 0 0 — 10 / 10 0 E T H E R N E T
Product Number Description
WS-X6148-RJ-21
48-port 10/100 upgradeable to voice, RJ-21
WS-X6148-21AF
PoE 802.3af 10/100, 48-port (RJ-21) line card
WS-X6148-RJ21V
48-port 10/100 Inline Power module, RJ-21
WS-X6148A-RJ-45
48-port 10/100 with TDR, upgradeable to PoE 802.3af
WS-X6148A-45AF
48-port PoE 802.3af 10/100, card with TDR
WS-X6148X2-RJ-45
96-port 10/100 (RJ-45), upgradeable to PoE 802.3af
WS-X6148X2-45AF
PoE 802.3af 10/100, 96-port ( RJ-45) line card
WS-X6196-RJ-21
96-port 10/100 upgradeable to PoE 802.3af
WS-X6196-21AF
96-port, PoE 802.3af 10/100-RJ-21
WS-X6548-RJ-21
48-port 10/100, RJ-21, fabric-enabled
WS-X6548-RJ-45
48-port 10/100, RJ-45, x-bar
CATA LY S T 6 5 0 0 10 F L /10 0 F X E T H E R N E T
Product Number Description
WS-X6024-10FL-MT
24-port 10BASE-FL MT-RJ module
WS-X6148-FE-SFP
48-port 100BASE-X module (requires SFP)
WS-X6524-100FX-MM
24-port 100FX, MT-RJ, fabric-enabled
Product Overview
Product Overview continued
CATA LY S T 6 5 0 0 — C H A S S I S
Product Number Description
WS-C6503-E
Enhanced 3-slot chassis, no fan or power supply
WS-C6504-E
Enhanced 4-slot 6500 chassis, no fan or power supply
WS-C6506-E
Enhanced 6-slot 6500 chassis, no fan or power supply
WS-C6509-E
Enhanced 9-slot 6500 chassis, no fan or power supply
WS-C6509-NEB-A
9-slot 6500 chassis (vertically oriented slots), no fan or power supply
WS-C6513
13-slot 6500 chassis, no fan or power supply
CATA LY S T 6 5 0 0 — S U P E R V I S O R E N G I N E S
Product Number Description
WS-SUP720-3B
Supervisor 720 fabric MSFC3 PFC3B
WS-SUP720
Supervisor 720 fabric MSFC3 PFC3A
WS-SUP32-10GE-3B
Supervisor 32 with 2 ports 10 GbE and PFC3B
WS-SUP32-GE-3B
Supervisor 32 with 8 GbE uplinks and PFC3B
CATA LY S T 6 5 0 0 — 10 G I G A B I T E T H E R N E T
Product Number Description
WS-X6704-10GE
4-port 10 Gigabit Ethernet module (requires XENPAK)
CATA LY S T 6 5 0 0 — G I G A B I T E T H E R N E T
Product Number Description
WS-X6408A-GBIC
8-port Gigabit Ethernet module, enhanced QoS (requires GBICs)
WS-X6516A-GBIC
16-port Gigabit Ethernet module, fabric-enabled (requires GBICs)
WS-X6724-SFP
24-port Gigabit Ethernet module, fabric-enabled (requires SFPs)
WS-X6748-SFP
48-port Gigabit Ethernet module, fabric-enabled (requires SFPs)

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
