Cisco Catalyst 4500 Series Quick Reference Guide

52
53
CATA LY S T 45 0 0 — B A S E C O N F I G U R AT I O N
Product Number Description
WS-C4503
3-slot chassis, fan, no power supply
WS-C4506
6-slot chassis, fan, no power supply
WS-C4507R
7-slot chassis, fan, no power supply, redundant-supervisor support
WS-C4510R
10-slot chassis, fan, no power supply, redundant-supervisor support
CATA LY S T 45 0 0 S U P E R V I S O R E N G I N E S
Product Number Description
WS-X4516-10GE
Catalyst 4500 Supervisor V-10 GbE, 2x10 GbE (X2) and 4x1 GbE (SFP)
WS-X4516
Catalyst 4500 Supervisor V (2 GbE), Console (RJ-45)
WS-X4515
Catalyst 4500 Supervisor IV (2 GbE), Console (RJ-45)
WS-X4013+10GE
Catalyst 4500 Supervisor Engine II-Plus-10GE,
2x10 GbE (X2) and 4x1 GbE (SFP)
WS-X4013+
Catalyst 4500 Supervisor II-Plus (IOS), 2 GbE, Console (RJ-45)
Cisco Catalyst 4500 Series
Series Spotlight
Product Overview continued
Scalable, Resilient
Architecture
The modular architecture of the Cisco
Catalyst 4500 Series provides the scalability
and flexibility to eliminate the need for
multiplatform deployments and minimizes
maintenance expenses. Network downtime
is minimized with redundant supervisor
engine (subsecond failover) capability
(Catalyst 4507R and Catalyst 4510R
switches), software-based fault tolerance,
redundant fans, and 1+1 power-supply
redundancy across the Cisco Catalyst
4500 Series. The scalable architecture
allows for easy upgrade of all system
ports to higher-layer switching functions
by simply adding a new supervisor engine
such as the Cisco Catalyst 4500 Series
Supervisor Engines II-Plus, IV, V or V-10
GbE. Higher-layer functional enhancements
such as NetFlow or Dynamic Buffer Limiting
are possible on all system ports without
replacing existing line cards and wiring.
Wire-speed Performance
with all Services Enabled
The Cisco Catalyst 4500 Series offers
up to 102 million packets per second
(mpps) wire-speed forwarding rate in
hardware for Layer 2–4 traffic. Switching
performance is independent of the
number of route entries or advanced
Layer 3 services enabled. This ensures
exceptional performance on applications
which are jitter and latency sensitive.
Product Overview
CATA LY S T 45 0 0 S U P E R V I S O R E N G I N E S c o n t i n u e d
Product Number Description
WS-X4013+TS
Catalyst 4503 Supervisor II-Plus-TS, 12 10/100/1000 PoE + 8 SFP slots
WS-F4531
Catalyst 4500 NetFlow services card
S45ES-12xxxx
Catalyst 4500 Enterprise Services Software
S45EK9-12xxxx
Catalyst 4500 Enterprise Services Software with 3DES
CATA LY S T 45 0 0 M O D U L E S
Product Number Description
WS-X4124-FX-MT
Catalyst 4500 FE Switching module, 24-port 100FX (MTRJ)
WS-X4124-RJ45
Catalyst 4500 10/100 module, 24 ports (RJ-45)
WS-X4148-FE-BD-LC
Catalyst 4500 FE module, 48-port BX-D (LC) (1550)
WS-X4148-FE-LX-MT
Catalyst 4500 FE module, 48-port 100LX-10 SMF (MTRJ)
WS-X4148-FX-MT
Catalyst 4500 FE Switching module, 48-port 100FX MMF (MTRJ)
WS-X4148-RJ
Catalyst 4500 10/100 Auto module, 48 ports (RJ-45)
WS-X4148-RJ21
Catalyst 4500 10/100 module, 48-port Telco (4xRJ21)
WS-X4148-RJ45V
Catalyst 4500 pre-standard PoE 10/100, 48 ports (RJ-45)
WS-X4224-RJ45V
Catalyst 4500 10/100 PoE 802.3af 24 ports (RJ-45)
WS-X4232-GB-RJ
Catalyst 4500 32-10/100 (RJ-45), 2 GbE (GBIC)
WS-X4232-RJ-XX
Catalyst 4500 10/100 module, 32 ports (RJ-45) + modular uplinks
WS-X4248-FE-SFP
Catalyst 4500 FE module, 48-port 100BASE-X (SFP optional)
WS-X4248-RJ21V
Catalyst 4500 PoE 802.3af 10/100, 48 ports (RJ-21)
WS-X4248-RJ45V
Catalyst 4500 PoE 802.3af 10/100, 48 ports (RJ-45)
WS-X4302-GB
Catalyst 4500 GbE module, 2 ports (GBIC)
WS-X4306-GB
Catalyst 4500 GbE module, 6 ports (GBIC)
WS-X4418-GB
Catalyst 4500 GbE module, Server Switching 18 ports (GBIC)
WS-X4424-GB-RJ45
Catalyst 4500 24-port 10/100/1000 module (RJ-45)
WS-X4448-GB-RJ45
Catalyst 4500 48-port 10/100/1000 module (RJ-45)
WS-X4448-GB-SFP
Catalyst 4500 48-port 1000BASE-X (SFPs optional)
WS-X4506-GB-T
Catalyst 4500 6-port 10/100/1000 PoE or SFP (optional)
WS-X4524-GB-RJ45V
Catalyst 4500 PoE 802.3af 10/100/1000 24 ports (RJ-45)
WS-X4548-GB-RJ45
Catalyst 4500 Enhanced 48-port 10/100/1000BASE-T (RJ-45)
WS-X4548-GB-RJ45V
Catalyst 4500 PoE 802.3af 10/100/1000, 48 ports (RJ-45)

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
