Cisco Catalyst 9120AX Series Access Points

For example, suppose that there are two controllers with management interface IP addresses, 10.126.126.2 and

10.127.127.2. The type is f1(hex). The length is 2 * 4 = 8 = 08 (hex). The IP addresses translate to 0a7e7e02 and

0a7f7f02. Assembling the string then yields f1080a7e7e020a7f7f02. The resulting Cisco IOS command added to the

DHCP scope is option 43 hex f1080a7e7e020a7f7f02.

Questions and Answers:

Need help?

Do you have a question about the Cisco Catalyst 9120AX Series and is the answer not in the manual?

General

Frequency Bands	2.4 GHz and 5 GHz
Antenna Type	Internal Antennas
PoE	802.3at PoE+
Wi-Fi Standard	802.11ax
MIMO	4x4 MU-MIMO
Weight	1.2 kg
Form Factor	Ceiling mount
Ethernet Ports	1 x 10/100/1000/2500 Multigigabit Ethernet port (RJ-45)
Dimensions	8.7 x 8.7 x 2.2 in
