Cisco Catalyst C9300-48U User Manual

Figure 34: Rear-Mounting Position
Figure 35: Four-Point Mounting Position
Installing the Switch on a Table or Shelf
Procedure
Step 1 To install the switch on a table or shelf, locate the adhesive strip with the rubber feet in the mounting-kit
envelope.
Step 2 Attach the four rubber feet to the four circular etches on the bottom of the chassis.
Step 3 Place the switch on the table or shelf near an AC power source.
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
59
Installing a Switch
Installing the Switch on a Table or Shelf

Cisco Catalyst C9300-48U Specifications

General

Model	C9300-48U
Stacking Bandwidth	480 Gbps
DRAM	8 GB
Flash Memory	16 GB
Stackable	Yes
PoE+	Yes
UPOE+	Yes
Power Supply	715W AC
Operating Temperature	-5 to 45°C
Ports	48 x 10/100/1000 UPOE+ ports
Dimensions	1.73 x 17.5 x 17.5 in. (4.4 x 44.5 x 44.5 cm)
