Figure 13: SIM Access Plate
Access plate screw1
Step 4 Install your SIMs as shown in the following figure. Make note of the slot number and SIM orientation.
Figure 14: SIM Installation
Micro SIMs1
SIM 02
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
45
Pluggable Interface Modules
Installing a PIM
