LINE-CARD QoS SUMMARY
Table 3 provides a summary of the QoS capabilities for each of the line cards in the Cisco Catalyst 6500 Family.
Table 3. QoS Capability Summary for Line Cards
xCEF720 Modules Description Receive Queue Structure Transmit Queue Structure Buffer Size
WS-X6704-10GE
Cisco Catalyst 6500 4-port 10-GbE 1q8t ‘ 8q8t with DFC3 1p7q8t 16 MB per port
WS-X6724-SFP
Cisco Catalyst 6500 24-port GbE SFP 1q8t ; 2q8t with DFC3a 1p3q8t 1 MB per port
WS-X6748-GE-TX
Cisco Catalyst 6500 48-port
10/100/1000 RJ45
1q8t ; 2q8t with DFC3a 1p3q8t 1 MB per port
WS-X6748-SFP
Cisco Catalyst 6500 48-port GbE SFP 1q8t ; 2q8t with DFC3a 1p3q8t 1 MB per port
WS-X6024-10FL-MT
Cisco Catalyst 6500 24-port
10BaseFL MT-RJ module
1q4t 2q2t 64 KB per port
WS-X6148-RJ21
Cisco Catalyst 6500 48-port 10/100
upgradable to voice; RJ-21
1q4t 2q2t 128 KB per port
WS-X6148-RJ21V
Cisco Catalyst 6500 48-port 10/100
inline power module; RJ-21
1q4t 2q2t 128 KB per port
WS-X6148-RJ45
Cisco Catalyst 6500 48-port 10/100;
upgradable to voice; RJ-45
1q4t 2q2t 128 KB per port
WS-X6148A-TJ45
Cisco Catalyst 6500 48-port 10/100
inline power enhanced; RJ-45
1q2t 1p3q8t 5.2 Mb per port
WS-X6148-RJ45V
Cisco Catalyst 6500 48-port 10/100
inline power; RJ-45
1q4t 2q2t 128 KB per port
WS-X6148-FE-SFP
Cisco Catalyst 6500 48-port 100-Mb
mod.; SFP
1q2t 1p3q8t 5.2 Mb per port
WS-X6148-GE-TX
Cisco Catalyst 6500 48-port
10/100/1000 GE mod.; RJ-45
1q2t 1p2q2t 1 MB per 8 ports
WS-X6148A-GE-TX
Cisco Catalyst 6500 48-port
10/100/1000 GE mod enhanced; RJ-
45
1q2t 1p3q8t 5.2 Mb per port
WS-X6148V-GE-TX
Cisco Catalyst 6500 48-port
10/100/1000 inline power module; RJ-
45
1q2t 1p2q2t 1 MB per 8 ports
WS-X6148X2-RJ-45
Cisco Catalyst 6500 96-port 10/100TX
mod.; RJ-45
1p1q0t 1p3q1t 1088 Kb per port
WS-X6196-RJ-21
Cisco Catalyst 6500 96-port 10/100
mod.; RJ-21
1p1q0t 1p3q1t 1088 Kb per port
WS-X6316-GE-TX
Cisco Catalyst 6500 16-port 1000TX
GE mod.; RJ-45
1p1q4t 1p2q2t 512 KB per port
WS-X6324-100FX-MM
Cisco Catalyst 6000 24-port 100FX;
enh QoS; MT-RJ; MMF
1q4t 2q2t 128 KB per port
WS-X6324-100FX-SM
Cisco Catalyst 6000 24-port 100FX;
enh QoS; MT-RJ; SMF
1q4t 2q2t 128 KB per port
