Cisco recommends an install torque range for the unistrut bolts between 40 and 50 to in.-lb (between 4.52
N-m and 5.65 N-m).
Caution
Figure 10: Attaching the Unistrut
Cutaway for ground cable3Upper grille support1
Unistruts2
What to Do Next
After the upper grille support has been installed, install the chassis ground cable. Continue to the Installing
the Chassis Ground Cable, on page 19 for more information.
Cisco CRS Routers 16-Slot Line Card Chassis Enhanced Router Installation Guide
18
Installing Power Components
Installing the Unistruts
