Installing the CTX2500 Card in the Cisco ONS 15310-MA
78-17333-01
CTX2500 Card Specifications
• Transmitter
– Maximum transmitter output power: Depends on the SFP used
(see the SFP specifications in the Cisco ONS 15310-CL and Cisco ONS 15310-MA Reference
Manual)
– Minimum transmitter output power: Depends on the SFP used
(see the SFP specifications in the Cisco ONS 15310-CL and Cisco ONS 15310-MA Reference
Manual)
– Center wavelength: See wavelength plan
– Center wavelength accuracy: 1 nm to 4 nm, depending on the SFP used
– Transmitter: DFB laser
• Receiver
– Maximum receiver level: Depends on the SFP used
(see the SFP specifications in the Cisco ONS 15310-CL and Cisco ONS 15310-MA Reference
Manual)
– Minimum receiver level: Depends on the SFP used
(see the SFP specifications in the Cisco ONS 15310-CL and Cisco ONS 15310-MA Reference
Manual)
– Receiver: PIN PD
– Receiver input wavelength range: Depends on the SFP used
(see the SFP specifications in the Cisco ONS 15310-CL and Cisco ONS 15310-MA Reference
Manual)
• Environmental
– Operating temperature:
C-Temp: +23 to +131 degrees Fahrenheit (–5 to +55 degrees Celsius)
I-Temp: –40 to +149 degrees Fahrenheit (–40 to +65 degrees Celsius)
– Operating humidity: 5 to 95 percent, noncondensing
– Power consumption: 9.28 W, 0.19 A, 31.68 BTU/hr
• Dimensions
– Height: 6.94 in. (167.28 mm)
– Width: 1.45 in. (36.83 mm)
– Depth: 8.35 in. (212.09 mm)
– Weight not including clam shell: 1.6 lb (0.73 kg)
LAN Port
• Supports a 10/100-Mbps Ethernet interface for Cisco Transport Controller/Transaction Language
One (CTC/TL1) provisioning.
