2 POWER—Connects the residential gateway to the AC power adapter that is
provided with your residential gateway
Important: Use only the power supply provided with your residential gateway.
3 TELEPHONE 1 and 2—RJ-11 telephone ports connect to home telephone wiring
to conventional telephones or fax machines. (Products shipping in North
America support lines 1 and 2 on port 1 when used with a two-line phone.)
4 USB (Optional for some models)—Connects to selected devices. For models that
support USB, the default is one USB port.
5 ETHERNET—Four RJ-45 Ethernet ports connect to the Ethernet port on your PC
or your home network
6 RESET—A momentary pressing (1-2 seconds) of this button performs a software
reset the device. Pressing and holding the button for more than ten seconds first
causes a reset-to-factory-default of all settings and then performs a software reset
of the device
CAUTION:
The RESET button is for maintenance purposes only. Do not use unless
any settings you have selected.
7 MAC ADDRESS LABEL—Displays the CM, EMTA, and WAN MAC addresses
for the residential gateway
8 CABLE—F-connector connects to an active cable signal from your service
provider
