Cisco DPC3941T User Manual

Initial Power Up, Calibration, and Registration (AC Power applied)
TP-00102 39
Front Panel LED Status Indicators During Initial Power Up, Calibration, and
Registration
Part 2, Telephone Registration
Step: 7 8 9 10 11
Front Panel
Indicator
Data Network
Registration
Complete
Requesting
Telephone IP
Address
Request
Telephone
Provisioning File
Restarting Voice
Servic e
Telephone
Registration
Complete
1
POWER
On
On
On
On
On
2
US/DS
On
On
On
On
On
3
ONLINE
On
On
On
On
On
4
2.4 GHz
On or
Blinking
On or Blinking
On or Blinking
On or Blinking
On or Blinking
5
5 GHz
On or
Blinking
On or Blinking
On or Blinking
On or Blinking
On or Blinking
6
TEL
1
Off
Blinking
Off
Blinking
On
7
TEL
2
Off
Off
Blinking
Blinking
On
8
BATTERY

On – When battery is charged

Blinks – When battery charge is low

Off – When there is no battery in the unit
