Cisco 10-Gigabit XFP Transceiver Modules Installation Note
OL-24246-01
Overview
Table 4 lists the port cabling specifications for the 10-Gigabit XFP transceiver modules.
4 192.1 1560.61 3 192.05 1561.01
2 192.0 1561.42 1 191.95 1561.83
Table 3 ITU 50-GHz Center Wavelengths and Channel Numbering (continued)
Channel ID Frequency
(THz)
Wavelength
(nm)
Channel ID Frequency
(THz)
Wavelength
(nm)
Table 4 XFP Transceiver Port Cabling Specifications
XFP Product Number Nominal
Wavelength
(nm)
Cable Type Core Size
(microns)
Modal
Bandwidth
(MHz/km)
Maximum Cabling Distance
XFP-10G-MM-SR= 850 MMF 62.5
62.5
50.0
50.0
50.0
160
200
400
500
2000
26 m (85.3 ft)
33 m (108.3 ft)
66 m (216.5 ft)
82 m (269 ft)
300 m (984.3 ft)
XFP-10GLR-OC192SR=
XFP10GLR-192SR-L=
XFP10GLR192SR-RGD=
1310 SMF G.652 — 10 km (6.2 miles)
10-Gigabit Ethernet
2 km (1.24 miles)
OC-192/STM-64 SR1
XFP-10GER-OC192IR=
XFP-10GER-192IR+=
XFP10GER-192IR-L=
XFP10GER192IR-RGD=
1550 SMF G.652 — 40 km (24.86 miles)
XFP-10GZR-OC192LR=
XFP10GZR192LR-RGD=
1550 SMF G.652 — 80 km (49.70 miles)
DWDM-XFP-xx.xx= See Table 2
on page 3
SMF G.652 — 80 km (49.70 miles)
DWDM-XFP-C= See Table 3
on page 4
SMF G.652 — 80 km (49.70 miles)
