Cisco DWDM-XFP Series User Manual

7
Cisco 10-Gigabit XFP Transceiver Modules Installation Note
OL-24246-01
Overview
Table 5 lists the XFP transceiver modules optical transmit and receive specifications.
Table 5 XFP Transceiver Optical Transmit and Receive Specifications
XFP Product Number Transceiver Operating Mode Transmit Power
(dBm)
Receive Power
(dBm)
Transmit and
Receive
Wavelength (nm)
XFP-10G-MM-SR= 10GBASE-SR, 850-nm MMF
(10.3125-Gbps line rate)
–1.0 (Max)
–7.3 (Min)
–1.2 (Max)
–9.9 (Min)
840 to 860
(TX and RX)
XFP-10GLR-OC192SR=
XFP10GLR-192SR-L=
XFP10GLR192SR-RGD=
10GBASE-LR, 1310-nm SMF
(10.3125-Gbps line rate)
+0.5 (Max)
–8.2 (Min)
+0.5 (Max)
–14.4 (Min)
1260 to 1355 (TX)
1260 to 1565 (RX)
OC-192/STM-64 SR1, 1310-nm
SMF
(9.95328-Gbps line rate)
–1.0 (Max)
–6.0 (Min)
–1.0 (Max)
–11.0 (Min)
1290 to 1330 (TX)
1260 to 1565 (RX)
XFP-10GER-OC192IR=
XFP-10GER-192IR+=
XFP10GER-192IR-L=
XFP10GER192IR-RGD=
10GBASE-ER, 1550-nm SMF
(10.3125-Gbps line rate)
+4.0 (Max)
–4.7 (Min)
–1.0 (Max)
–15.8 (Min)
1530 to 1565 (TX)
1260 to 1565 (RX)
OC-192/STM-64 IR2, 1550-nm
SMF
(9.95328-Gbps line rate)
+2.0 (Max)
–1.0 (Min)
+2.0 (Max)
–14.0 (Min
1530 to 1565 (TX)
1260 to 1565 (RX)
XFP-10GZR-OC192LR=
XFP10GZR192LR-RGD=
10GBASE-ZR, 1550-nm SMF
(10.3125-Gbps line rate)
OC-192/STM-64 LR2, 1550-nm
SMF
(9.95328-Gbps line rate)
+4.0 (Max)
0 (Min)
–7.0 (Max)
–24 (Min)
1530 to 1565 (TX)
1260 to 1565 (RX)
