Front Panel
1 VOL +, VOL - Increases and decreases the volume
2 CH+, CH - Scrolls up and down through the channels
3 Select Provides access to your on-screen selection
4 Display Displays the selected channel number and time of day. The display shows the following:
• Record (
) • Auto • 1080i / 1080P • MoCA Link ( )
• Power (
) • Message ( ) • 720i / 720P Illuminates when this set-top
• 5.1 • HDTV • 480i / 480P is connected to a server
5 Guide Accesses on-screen services, such as the on-screen guide, video-on-demand, or pay-per-view
6 Info Displays a description of the selected program. This button is available from the on-screen guide
and while viewing a program
7 Exit Exits menus, the on-screen guide, and program information
8 Settings Provides access to the Settings menu
9 IR Sensor Receives the infrared signal from the remote control
10 USB Port Connects to external equipment, such as a keyboard or mouse
(reserved for future use)
11 Power Turns the set-top on and off
Note: This illustration may vary from the actual product.
T14051
