Cisco Firepower 1140 User Manual

Figure 24: Install the Chassis in the Rack
Rack-mount bracket2Rack-mount bracket1
Hot aisle
Chassis non-I/O side (front panel)
4Cold aisle
Chassis I/O side (rear panel)
3
—Air flow direction (I/O side to non-I/O side)5
What to do next
You can now install the cables and power cord, as described in the Cisco Firepower 1100 Getting Started
Guide.
Cisco Firepower 1100 Series Hardware Installation Guide
27
Rack-Mount the Chassis
Rack-Mount the Chassis

Cisco Firepower 1140 Specifications

General

Processor cores	16
Processor family	Intel
Built-in processor	Yes
Firewall throughput	2200 Mbit/s
IPSec VPN throughput	1.2 Gbit/s
Maximum firewall connections	400000
Maximum firewall connections per second	100000
Wi-Fi	No
Supported network protocols	SMTP
Console port	RJ-45
Connectivity technology	Wired
SFP module slots quantity	4
Ethernet LAN (RJ-45) ports	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
SSD capacity	200 GB
Storage media type	SSD
Form factor	1U
Input current	2 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Country of origin	Mexico
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	1409.7 mm
Package width	990.6 mm
Package height	457.2 mm
Package weight	5782.31 g

Weight and Dimensions

Depth	436.9 mm
Width	268.7 mm
Height	43.7 mm
