Connecting to an SDTV with a SCART Connector
Cables Used in this Con guration
MiniDin to SCART Adapter Cable
WARNING:
Electric shock hazard! Unplug all electronic devices before connecting or
disconnecting any device cables to the set-top.
Back of Set-Top
S/PDIF SCART HDMI ETHERNET Reset
12V DC
CABLE/
ANTENNA
SCART VIDEO IN
Back of TV
CABLE/
ANTENNA
SCART VIDEO IN
T16450
