Connecting to an HDTV with a DVI Connector
Cables Used in this Con guration
• 1 HDMI-to-DVI Cable or 1 HDMI Cable and 1 HDMI-to-DVI Adapter
• 1 Audio Left/Right Cable (You can also use an optical cable [indicated by the dotted
line] instead of the Audio Left/Right Cable as shown in the diagram, dependent upon
your TV’s capabilities.)
Notes:
• The DVI port on the TV must support high-bandwidth digital content protection (HDCP).
• When you connect the HDMI connector to the DVI connector on your HDTV, you need
an HDMI-to-DVI adapter and a separate audio connection.
WARNING: Electric shock hazard! Unplug all electronic devices before
connecting or disconnecting any device cables to the receiver.
Receiver
