Cisco Linksys EA2700 User Manual

36
Setting Up: Advanced
Linksys EA-Series
c. In the Destination section, select MAC Address, then click DHCP
Client Table. A separate window opens showing the current DHCP
client list.
TIP
The DHCP Client Table is only available if you select MAC Address.
d. Click Select next to the device that you want to place in the DMZ. In
this example, the first device was selected. The corresponding MAC
address was copied into the MAC Address field as shown below.
e. Click Save Settings to apply your changes.

Cisco Linksys EA2700 Specifications

General

Brand	Cisco Linksys
Model	EA2700
Wireless Standards	802.11a/b/g/n
Antenna Type	Internal
Frequency Bands	2.4 GHz
Security Features	WEP, WPA, WPA2
Wireless Speed	Up to 300 Mbps (2.4 GHz) + 300 Mbps (5 GHz)
Weight	0.79 lbs
