4 Cisco Mini-GBIC SFP Transceiver Quick Start Guide
STEP 4 Connect the other end of the cable to an SFP module to verify that
the fiber connection is complete.
For the Cisco MGBBX1, use the Cisco GLC-BX-D as the
downstream SFP. For the Cisco MFEBX1, use the Cisco GLC-FE-
100BX-D as the downstream SFP. The Cisco MGBBX1 and the
Cisco MFEBBX1 support upstream only.
Connecting the Cisco MGBT1
STEP 1 Insert the gigabit SFP module with the printed side up and the pull
tab facing out.
STEP 2 Lock the gigabit SFP module in place.
STEP 3 Connect the cable to the gigabit SFP Module’s port.
STEP 4 Connect the other end of the cable to the switch.

Cisco MGBBX1 Specifications

General

Brand	Cisco
Model	MGBBX1
Category	Transceiver
Language	English
