Cisco PIX-515E User Manual

8
c. Select the Translation Rules tab.
d. Click the Manage Pools button and a new window appears, allowing you to add or edit global
address pools.
Note For most configurations, global pools are added to the less secure, or public, interfaces.
In the Manage Global Address Pools window:
a. Select the dmz interface.
b. Click the Add button.
In the Add Global Pool Item window:
a. Select dmz from the Interface drop-down menu.

Cisco PIX-515E Specifications

General

Concurrent Sessions	130, 000
Stateful Inspection	Yes
Maximum Connections	130, 000
RAM	128 MB
Flash Memory	16 MB
Power Supply	Internal AC
Operating System	Cisco PIX OS
Interfaces	6 x 10/100 Ethernet
High Availability	Yes
Weight	15 lbs
Firewall Type	Stateful Packet Inspection
Form Factor	Rackmount
VPN Throughput	Up to 100 Mbps (3DES)
