CHAPTER
Connecting Ethernet Network Modules to a Network 4-1
4
Connecting Ethernet Network
Modules to a Network
This chapter describes how to connect and configure Ethernet network modules in Cisco
modular routers, and describes the following modules:
• 1-Port and 4-Port Ethernet Modules on page 4-1
• 1-Port Fast Ethernet Module on page 4-5
1-Port and 4-Port Ethernet Modules
This section provides information about the following network modules for Cisco modular
routers:
• 1-port Ethernet network module—(Cisco product number NM-1E). (See Figure 4-1.)
• 4-port Ethernet network module—(Cisco product number NM-4E). (See Figure 4-2.)
Figure 4-1 1-Port Ethernet Network Module
EN
ETH 0
ETHERNET
1E
ACT
LINK
H9251
10BaseT
port
AUI
port
