Cisco Small Business 200 Series Smart Switch Administration Guide 13

Contents

Table of Contents

Default Chapter2
- Table of Contents2
Chapter 1: Getting Started14
- Starting the Web-Based Configuration Utility14
  - Launching the Configuration Utility15
    - Http/Https16
    - Logging out17
- Quick Start Device Configuration18
- Interface Naming Conventions18
- Window Navigation20
  - Application Header20
  - Management Buttons22
Chapter 2: Status and Statistics25
- Viewing Ethernet Interfaces25
- Viewing Etherlike Statistics26
- Viewing 802.1X EAP Statistics27
- Managing RMON29
Chapter 3: Administration: System Log39
- Setting System Log Settings39
- Setting Remote Logging Settings41
- Viewing Memory Logs42
  - RAM Memory43
  - Flash Memory43
Chapter 4: Administration: File Management45
- System Files45
- Upgrade/Backup Firmware/Language48
  - Upgrade/Backing Firmware or Language File49
- Download/Backup Configuration/Log52
  - Configuration File Backwards Compatibility52
  - Downloading or Backing-Up a Configuration or Log File53
- Configuration Files Properties57
- Copy/Save Configuration58
- DHCP Auto Configuration60
Chapter 5: Administration: General Information67
- Device Models67
- System Information69
  - Displaying the System Summary69
  - Configuring the System Settings70
- Rebooting the Device71
- Monitoring Fan Status73
- Defining Idle Session Timeout74
- Pinging a Host75
Chapter 6: Administration: Time Settings77
- System Time Options78
  - Time78
  - Time Zone and Daylight Savings Time (DST)79
- SNTP Modes79
- Configuring System Time80
Chapter 7: Administration: Diagnostics87
- Testing Copper Ports87
- Displaying Optical Module Status89
  - MSA-Compatible Sfps89
- Configuring Port and VLAN Mirroring90
- Viewing CPU Utilization and Secure Core Technology92
Chapter 8: Administration: Discovery93
- Configuring Bonjour Discovery93
  - Bonjour in Layer 2 System Mode93
- LLDP and CDP94
- Configuring LLDP95
- Configuring CDP115
Chapter 9: Port Management125
- Configuring Ports125
- Setting Port Configuration126
- Configuring Link Aggregation129
- Configuring Green Ethernet136
Chapter 10: Smartport145
- Overview145
- What Is a Smartport146
- Smartport Types146
  - Special Smartport Types148
- Smartport Macros149
  - Applying a Smartport Type to an Interface149
- Macro Failure and the Reset Operation150
- How the Smartport Feature Works151
- Auto Smartport151
- Error Handling155
- Default Configuration155
- Relationships with Other Features and Backwards Compatibility156
- Common Smartport Tasks156
- Configuring Smartport Using the Web-Based Interface158
- Built-In Smartport Macros163
Chapter 11: Port Management: Poe175
- Poe on the Device175
- Configuring Poe Properties178
- Configuring Poe Settings179
  - Poe Priority Example179
Chapter 12: VLAN Management183
- Vlans183
- Configuring Default VLAN Settings186
- Creating Vlans187
- Configuring VLAN Interface Settings188
- Defining VLAN Membership189
  - Configuring Port to VLAN190
  - Configuring VLAN Membership191
- Voice VLAN192
Chapter 13: Spanning Tree207
- STP Flavors207
- Configuring STP Status and Global Settings208
- Defining Spanning Tree Interface Settings210
- Configuring Rapid Spanning Tree Settings212
Chapter 14: Managing MAC Address Tables215
- Types of MAC Addresses215
- Configuring Static MAC Addresses216
- Managing Dynamic MAC Addresses217
  - Configuring Dynamic MAC Address Aging Time217
  - Querying Dynamic Addresses217
Chapter 15: Multicast219
- Multicast Forwarding219
  - Typical Multicast Setup220
  - Multicast Address Properties221
- Defining Multicast Properties222
- Adding MAC Group Address223
- Adding IP Multicast Group Addresses225
- Configuring IGMP Snooping227
- MLD Snooping229
- Querying IGMP/MLD IP Multicast Group231
- Defining Multicast Router Ports232
- Defining Forward All Multicast233
- Defining Unregistered Multicast Settings234
Chapter 16: IP Configuration237
- Overview237
  - Layer 2 IP Addressing237
- Ipv4 Management and Interfaces238
- Domain Name252
Chapter 17: Security257
- Defining Users258
  - Setting User Accounts258
  - Setting Password Complexity Rules259
- Configuring RADIUS261
- Configuring Management Access Authentication264
- Defining Management Access Method265
  - Active Access Profile266
  - Defining Profile Rules268
- SSL Server270
- Configuring TCP/UDP Services272
- Defining Storm Control274
- Configuring Port Security275
- Configuring 802.1X278
- Denial of Service Prevention284
Chapter 18: Security: SSH Client289
- Secure Copy (SCP) and SSH289
- Protection Methods290
- SSH Server Authentication292
- SSH Client Authentication293
  - Supported Algorithms293
- Before You Begin294
- Common Tasks294
- SSH Client Configuration through the GUI296
Chapter 19: Security: Secure Sensitive Data Management299
- Introduction299
  - SSD Management300
- SSD Rules300
- SSD Properties305
- Configuration Files308
- SSD Management Channels313
- Menu CLI and Password Recovery314
- Configuring SSD314
  - SSD Properties314
  - SSD Rules315
Chapter 20: Quality of Service317
- Qos Features and Components318
  - Qos Operation318
  - Qos Workflow319
- Configuring Qos - General319
- Managing Qos Statistics330
  - Viewing Queues Statistics330
Chapter 21: SNMP333
- SNMP Versions and Workflow333
- Model Oids336
- SNMP Engine ID337
- Configuring SNMP Views338
- Creating SNMP Groups340
- Managing SNMP Users342
- Defining SNMP Communities344
- Defining Trap Settings346
- Notification Recipients346
  - Defining Snmpv1,2 Notification Recipients347
  - Defining Snmpv3 Notification Recipients348
- SNMP Notification Filters350
