Cisco Small Business 200 - Page 326

Quality of Service
Configuring QoS - General
313 Cisco Small Business 200 Series Smart Switch Administration Guide
20
DSCP
59 51 43 35 27 19 11 3
Queue
3343 3 2 1 1
DSCP
58 50 42 34 26 18 10 2
Queue
3343 3 2 1 1
DSCP
57 49 41 33 25 17 9 1
Queue
3343 3 2 1 1
DSCP
56 48 40 32 24 16 8 0
Queue
3343 3 2 1 1
Table 5 DSCP to Queue Default Mapping – 8 Queues System (7 is highest
and 8 is used for stack control purposes)
DSCP
63 55 47 39 31 23 15 7
Queue
667 54321
DSCP
62 54 46 38 30 22 14 6
Queue
667 54321
DSCP
61 53 45 37 29 21 13 5
Queue
667 54321
DSCP
60 52 44 36 28 20 12 4
Queue
667 54321
DSCP
59 51 43 35 27 19 11 3
Queue
667 54321
DSCP
58 50 42 34 26 18 10 2
Queue
667 54321
DSCP
57 49 41 33 25 17 9 1
Table 4 DSCP to Queue Default Mapping – 4 Queues System
