DescriptionFeature
Rear panel:
• One 1-Gb Ethernet dedicated management port (RJ-45 connector)
• Two 1-Gb/10-Gb BASE-T Ethernet LAN ports (RJ-45 connectors)
The dual LAN ports can support 10 Gbps, 1 Gbps, 100 Mbps, or 10 Mbps. The LAN ports
autonegotiate to the correct link speed based on the link partner capability.
• One RS-232 serial port (RJ-45 connector)
• One VGA video connector port (DB-15 connector)
• Two USB 3.0 ports
Front panel:
• One front-panel keyboard/video/mouse (KVM) connector that is used with the KVM breakout
cable. The breakout cable provides two USB 2.0, one VGA, and one DB-9 serial connector.
Network and management I/O
One dedicated socket (x16 PCIe lane) that can be used to add an mLOM card for additional rear-panel
connectivity. As an optional hardware configuration, the Cisco CNIC mLOM module supports two
100G QSFP+ ports or four 25 Gbps Ethernet ports.
Modular LOM
• 1050 W (AC)
• 1050 W (DC)
Power
Supports advanced configuration and power interface (ACPI) 4.0 standardACPI
The front panel provides status indications and control buttonsFront Panel
Eight hot-swappable fan modules for front-to-rear coolingCooling
In addition to Fibre Channel, Ethernet and other industry-standards, the PCI slots in this server support
the InfiniBand architecture up HDR IB (200 Gbps).
InfiniBand
Three half-height riser slots:
• Riser 1 (controlled by CPU 1): One x16 PCIe Gen4 Slot, half-height, 3/4 length
• Riser 2 (controlled by CPU 1): One x16 PCIe Gen4 Slot, half-height, 3/4 length
• Riser 3 (controlled by CPU 2): One x16 PCIe Gen4 Slot, half-height, 3/4 length
Two full-height riser slots:
• Riser 1 (controlled by CPU 1): One x16 PCIe Gen4 Slot, full-height, 3/4 length
• Riser 2 (controlled by CPU 2): One x16 PCIe Gen4 Slot, full-height, 3/4 length
Expansion Slots
Cisco Secure Network Server 3700 Series Appliance Hardware Installation Guide
13
Cisco Secure Network Server 3700 Series Appliance Overview
Summary of Server Features
