Motherboard CPU socket (CPU1)12Modular LOM (mLOM) card bay on
chassis floor (x16 PCIe lane)
The mLOM card bay is below PCIe riser
slot 1.
11
—Front Panel Controller board13
Summary of Server Features
The following table lists a summary of server features.
DescriptionFeature
One rack-unit (1RU) chassisChassis
Up to two 3rd Generation Intel Xeon processorsCentral Processor
32 slots for registered DIMMs (RDIMMs), DDR4 DIMMs, 3DS DIMMs, and load-reduced DIMMs
(LR DIMMs) up to 3200 MHz. Also supports Intel Optane Persistent Memory Modules (PMEMs)
Memory
Supports multi-bit error protectionMulti-bit error protection
The Cisco Integrated Management Controller (Cisco IMC) provides video using the Matrox G200e
video or graphics controller:
• Integrated 2D graphics core with hardware acceleration
• DDR3 memory interface supports up to 512 MB of addressable memory (8 MB is allocated by
default to video memory)
• Supports display resolutions up to 1920 x 1200 16bpp at 60Hz
• High-speed integrated 24-bit RAMDAC
• Single lane PCI-Express host interface running at Gen 2 speed
Video
BMC, running Cisco IMC firmware.
Depending on your Cisco IMC settings, Cisco IMC can be accessed through the 1-Gb dedicated
management port, the 1-Gb/10-Gb Ethernet LAN ports, or a Cisco virtual interface card.
Baseboard management
Cisco Secure Network Server 3700 Series Appliance Hardware Installation Guide
12
Cisco Secure Network Server 3700 Series Appliance Overview
Summary of Server Features
