Cisco TelePresence IX5000 and IX5200 First-Time Setup
OL-27038-01
Performing First-Time Setup
• The whiteboard microphone should be approximately 8 feet (2.44 meters) from the floor, and
approximately 18 inches (46 cm) from the whiteboard.
Tip Wired or wireless microphones are permitted. A boom is not required.
Figure 6 Whiteboard Microphone Placement Example
393512
Height
8 feet
