Installing Cisco TelePresence MX300 G2 - Floor Stand
78-100143-01 | OCTOBER 2013 | © 2013 Cisco Systems, Inc. All rights reserved.
2
Mounting the monitor
Use gloves when
handling the monitor.
Remove the cable
channel lid for now.
You need it in step 4.
The monitor may be tilting slightly
forward. If you gently pull it to a vertical
position, the screws enter more easily.
Front
4 × M6x16
B
C
