Installing Cisco TelePresence MX300 G2 - Floor Stand
78-100143-01 | OCTOBER 2013 | © 2013 Cisco Systems, Inc. All rights reserved.
3
Connecting the cables
For maintenance only
Reset to factory settings
Audio line output
Always use the provided
power cable.
The wall socket outlet must
be easily accessible after
installation.
Power switch
Audio line input
LAN
**
Video input
(e.g. PC
*
)
Video output
(e.g. 2
nd
display
*
)
Power
(100-240 VAC,
50/60 Hz)
Microphones
Touch
controller
**
USB, for future use
HDMI
DVI-I
*
Optional
**
Use the cable that is labeled
with for the Touch controller;
use the cable that is labeled
with for the LAN
C
D
