Cisco Telepresence MX800 Quick Start Guide

Quickstart Guide | Cisco Telepresence MX Series
4
Quickstart Guide | Cisco Telepresence MX Series
5
Place a call
Use any of the following approaches to place a call:
Place a call from Contact List
› Tap the Contacts options, search for someone in a specic list
by tapping that list and scrolling to locate the entry.
› Alternatively, tap the Search or Dial eld which will invoke the
virtual keyboard. Key in the name, number or IP address and
matches will appear as you type. If you need to edit the entry
before you call, tap the More option, and tap Edit & Call which
will invoke the virtual keyboard. Apply the editing. When you
are ready to place the call, press the green Call icon.
Place call using Name
› Tap Dial which will show the numerical dialpad.
› Tap Keyboard and key in the name. Matches will appear as
you type.
› Press the green Call icon when you are ready to place
the call.
Placing and Receiving Calls Placing and Receiving Calls
Place call using an IP address
› Tap Dial and enter the IP address into the numerical dialpad.
Tap and hold * to type the point sign used in
IP addresses.
› Press the green Call icon when you are ready to place
the call.
Place call using Number
› Tap Dial and enter the number into the numerical dialpad.
› Press the green Call icon when you are ready to place
the call.

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
