Conference Calls Conference Calls
Add Additional Participants to Existing Call
If your video system allows, you may have the capability to initiate
a video conference with several participants. You must call each
participant one by one.
› While in a call tap Add and locate whom to call, tap Call.
› You may be prompted to tap Merge. This will create the
conference. You may cancel this call without terminating the
rst call you were in by tapping Cancel.
View Meeting Participants List
› In a call, swipe your nger horizontally to the left or tap the
small grey dot. A list will show all the participants, even if they
are on Hold.
Lock Speaker
› During a conference call, voice switching will be active.
This is where the screen will display the speaker. If you wish
to keep the view on one of the participants, you can utilise the
lock speaker.
› While this person is speaking, tap that speaker’s avatar.
Tap Lock as speaker. Once this is activated the eld will
change to Unlock as speaker which you can press to enable
voice switching.
Disconnect Participant from Call
To disconnect a participant from a call:
› Bring up the list of participants and Tap the participant you
wish to disconnect.
› Tap Drop. The participant will be disconnected.
Share Content
Your video system supports the ability to show presentations
during a video call or conference as well as outside a call.
› Tap Present then scroll horizontally to locate the
presentation source. Tap the required source.
› To stop the presentation, tap Stop Presenting.
› To change the Presentation Layout tap Layout and tap your
preferred layout.

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
