Cisco TelePresence System EX Series Administrator Guide
D14726.14 EX Series Administrator Guide TC7.1, APRIL 2014. www.cisco.com — Copyright © 2010–2014 Cisco Systems, Inc. All rights reserved.
125
* Requires premium resolution option
operAting temperAture And humidity
• Ambient temperature: 0° C to 35° C (32° F to 95° F)
• Relative Humidity (RH): 10 to 90%
• Storage and transport temperature at RH 10–90% (non-
condensing): -20° C to 60° C (-4° F to 140° F)
mAin unit dimensions
EX90:
• Height: 54.5 cm (21.4 in.)
• Length: 56.7 cm (22.3 in.)
• Depth: 17.3 cm (6.8 in.)
• Weight: 11.0 kg (24.2 lb)
EX60:
• Height: 50.8 cm (20.0 in.)
• Length: 52.0 cm (20.5 in.)
• Depth: 13.8 cm (5.4 in.)
• Weight: 5.85 kg (12.9 lb)
touch screen dimensions
Without handset:
• Height: 4.4 cm (1.7 in.)
• Length: 22.8 cm (9.0 in.)
• Depth: 14.5 cm (5.7 in.)
• Weight: 0.64 kg (1.4 lb)
• Cable length: 120 cm (47 in.)
With handset:
• Height: 7.7 cm (3.0 in.)
• Length: 29.0 cm (11.4 in.)
• Depth: 18.7 cm (7.4 in.)
• Weight: 0.94 kg (2.1 lb)
• Cable length: 120 cm (47 in.)
bAndwidth
• H.323/SIP up to 6 Mbps point-to-point
Audio stAndArds
• G.711, G.722, G.722.1, G.729AB
EX90:
• 64 kbps and128 kbps
AAC-LD, mono and stereo
EX60:
• 64 kbps AAC-LD
Audio feAtures
• CD quality 20 kHz stereo
• Acoustic echo canceling
• Automatic gain control
• Automatic noise reduction
• Active lip synchronization
Video stAndArds
• H.261, H.263, H.263+, H.264
Video feAtures
• Widescreen: 16:9
• Advanced screen layouts
• Intelligent video management
• Local auto layout
LiVe Video resoLutions (encode/decode)
• 176 × 144@30 fps (QCIF)
• 352 × 288@30 fps (CIF)
• 512 × 288@30 fps (w288p)
• 576 × 448@30 fps (448p)
• 768 × 448@30 fps (w448p)
• 704 × 576@30 fps (4CIF)
• 1024 × 576@30 fps (w576p)
• 640 × 480@30 fps (VGA)
• 800 × 600@30 fps (SVGA)
• 1024 × 768@30 fps (XGA)
• 1280 × 1024@30 fps (SXGA)
• 1280 × 720@30 fps (720p30)
• 1280 × 768@30 fps (WXGA)
• 1920 × 1080@30 fps (1080p30)*
• 1440 × 900@30 fps (WXGA+)*
• 1472 × 1080@30 fps (SXGA+)*
• 1680 × 1050@30 fps (WSXGA+)*
• 1600 × 1200@30 fps (UXGA)*
• 512 × 288@60 fps (w288p60)*
• 768 × 448@60 fps (w448p60)*
• 1024 × 576@60 fps (w576p60)*
• 1280 × 720@60 fps (720p60)*
Only EX90:
• 1920 × 1200@25fps (WUXGA)*
duAL streAm
• H.239 (H.323) dual stream
• BFCP (SIP) dual stream
EX90:
• Supports resolutions up
to 1080p in both main
stream and dual stream
simultaneously
EX60:
• Supports resolutions up to
720p in both main stream and
dual stream simultaneously
protocoLs
• H.323
• SIP
• ISDN (requires Cisco TelePresence ISDN Link)
networK interfAces
• Internal 2-port Ethernet switch
• 1 × LAN/Ethernet (RJ-45) 10/100/1000 Mbit for PC
• 1
× LAN/Ethernet (RJ-45) 10/100/1000 Mbit for LAN
other interfAces
• Bluetooth
EX90:
• 2 × USB device for future
applications
EX60:
• 1 × USB device for future
applications
ip networK feAtures
• Domain Name System (DNS) lookup for service configuration
• Differentiated Services (QoS)
• IP adaptive bandwidth management (including flow control)
• Auto gatekeeper discovery
• Dynamic playout and lip-sync buffering
• H.245 DTMF tones in H.323
• Date and time support with Network Time Protocol (NTP)
• Packet loss based downspeeding
• DNS-based URI dialing
• TCP/IP
• Dynamic Host Configuration Protocol (DHCP)
• IEEE 802.1x network authentication
• IEEE 802.1q VLAN
• IEEE 802.1p QoS and class of service (CoS)
• ClearPath
• Medianet: Mediatrace and Metadata
ipV6 networK support
• Single call stack support for both H323 and SIP
• Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS,
DiffServ
• Support for both static, autoconfiguration (stateless address
autoconfiguration) and DHCPv6
