Cisco UCS C220 M4 NEBS Server Service Note
Power Supply Specifications
770 W AC Power Supply Specifications
Table 2 lists the specifications for each 770 W AC power supply (Cisco PID UCSC-PSU1-770W=).
Table 2 770 W AC Power Supply Specifications
Description Specification
AC input voltage Nominal range: 100–120 VAC, 200–240 VAC
(Range: 90–132 VAC, 180–264 VAC)
AC input frequency Nominal range: 50 to 60Hz
(Range: 47–63 Hz)
Maximum AC input current 9.5 A at 100 VAC
4.5 A at 208 VAC
Maximum input volt-amperes 950 VA at 100 VAC
Maximum output power per PSU 770 W
Maximum inrush current 15 A (sub-cycle duration)
Maximum hold-up time 12 ms at 770 W
Power supply output voltage 12 VDC
Power supply standby voltage 12 VDC
Efficiency rating Climate Savers Platinum Efficiency (80Plus Platinum
certified)
Form factor RSP2
Input connector IEC320 C14
