C H A N G I N G B U L B S
HEADLAMP UNIT
1 Sidelamp
2 Dipped beam
3 Main beam
4 Direction indicator
Note:
A light misting may appear
on the headlamp surface in certain
conditions of use.
Dipped beam
Main beam
Tilt the metallic spring holding the
fl ap giving access to the lamp
bulbs.
Open the access fl ap.
Disconnect the connector.
Disengage the retaining spring by
an forward movement, then an out-
ward movement to disengage the
two grips.
Take out the bulb.
Bulb: H4
Before touching, disconnect the supply connector A.
