AIR
CONDITIONING
256
C5HP15TP
AIR CONDITIONING SYSTEM R 134.a
Engine : 4HX
(1) High pressure valve.
(2) Low pressure valve.
(3) Pressostat.
(4) Capacity.
(a) Condenser bracket
Tighten to 0,8 m.daN
(b) Pressure control valve
Tighten to 0,8 m.daN
(c) Compressor bracket
Tighten to 2,5 ± 0,1 m.daN
(d) Condenser dryer reservoir
Tighten to 1,4 ± 0,2 m.daN.
