ENGINE
47
Engine : XFX
SPECIAL FEATURES : TIGHTENING TORQUES ( m.daN)
(8) Crankshaft bearings
Carry out the following operations :
- Clean the threads of the screws with a brush.
- Refit the screws with a coating of grease, on threads and under
heads "MOLYKOTE G RAPID PLUS".
- Check that the 8 centring pins are in place.
Tightening :
- Pre-tightening M11 to 3 ± 0.3 (Order from 1 to 8)
- Pre-tightening M8 to 1 ± 0.1 (Orer from A to H)
- Tightening M6 to 1 ± 0.1 (Order from a to m)
- Untightening M11 to M8
Proceed screw by screw :
- Tightening M11 to 3 ± 0.3 (order from 1 to 8), then
One angular tightening of 180°
- Tightening M8 to 1 ± 0,1 (Order from A to H), then
One angular tightening of 180°
Max. length under heads of the screws M11 = 131.5 mm.
Max. length under heads of the screws M8 = 119 mm.
