ENGINE
53
CYLINDER HEAD
Engine : XFX
Camshafts
Marking of the camshafts at «d».
(6) Exhaust camshaft (front cylinder head) A 389
(7) Inlet camshaft (front cylinder head) A 423
(8) Inlet camshaft (rear cylinder head) E 422
(9) Exhaust camshaft (rear cylinder head) E 388
Valve clearances when cold.
Hydraulic followers with automatic clearance adjustment.
B1EP150D
